LR Series
Double-Pole Rocker Switch
Features
?
?
?
?
Single-throw and double-throw options
Lighted and non-lighted options
Industry standard mounting dimensions
Mechanical life: min. 100,000 operations
Electrical Ratings
Electrical Life at Rated Load
Switch
Series
LR
EN61058 Rating
10(4)A, 250V~T125/55
UL1054 Rating
10A 125VAC 1/4HP,
8A 250VAC; 1/4HP
According to VDE
(Min. Operations)
10,000
According to UL
(Min. Operations)
6,000
Electrical Specifications
Material Specifications
10A 125VAC 1/4HP
Actuator: (non-lighted)
Nylon 66 94V-2
Ratings:
Dielectric Strength:
Insulation Resistance:
Initial Contact Resistance:
Temperature Range:
8A 250VAC 1/4HP (cULus)
10(4)A, 250V~ T125/55 (VDE)
1000VAC for 1 minute
100M ohms min at 500VDC
0.020 ohms max
-20°C to + 65°C
(lighted)
Base:
Spring:
Contacts:
Movable Arm:
Terminals:
Polycarbonate
Nylon 66 94V-2
Steel Wire
Silver Alloy
Copper Alloy
Tin-Plated Copper Alloy
RoHS Compliant
UL File No: E23301
Specifications subject to change without notice.
